Lara XXL Vacuum Sterilizer with 38 Litre Chamber.
Xceeding Limits.
Offering extra capacity for high demand clinics whilst still offering premium cycle performance thanks to its Eco Dry+ technology.
The Lara sterilizer range provides an innovative midrange sterilizer with unique upgradeability for future or individual demands. Lara’s offer a wealth of features not seen in other midrange sterilizers, now extended to a 38 litre chamber with all the benefits.
Main product advantages of the new Lara XXL:
- High capacity: Lara XXL offers a 38 litre chamber, allowing for the reprocessing of up to 10 kg of wrapped items and 12 kg of containers. This is an ideal unit for practices with high turnover of instruments as it has approximately double the capacity of a standard sterilizer. The chamber dimensions and the 6-tray rack offer flexibility to permit the reprocessing of a wide range of loads.
- Dimensions: the Lara XXL is compact and can be installed on a standard 600 mm worktop. Dimensions: (W) 492 x (H) 455 x (D) 797 mm, so there may be an overhang dependent on worktop depth.
- Workflow optimization: the advanced patented Eco Dry technology adjusts the drying time to the mass of the load: a 3 kg load is reprocessed in approximately 40 minutes. This reduces the cycle time, increases the life span of your instruments and optimizes the energy consumption.
- Simple daily operation: thanks to touch screen display, intuitive menu structure and automatic water filling.
- Cutting-edge connectivity: thanks to 5 built-in USB ports and the Ethernet connection that guarantees compatibility with ioDent and W&H Steri App.
- Enhanced traceability: Lara XXL records cycle reports and the user identification for the launch and release of the sterilization cycle. Label and thermal printers can be connected.
- Upgradability: the innovative Activation Code System allows customization and upgrading of the Lara XXL functionalities, to meet future needs.
Technical data:-
- EN13060 Classification: B Type
- Chamber Size: 38L
- Power Supply: 200–240 V AC; 50/60 Hz; 12 A
- Overall Dimensions: 492 x 455 x 797 mm
- Weight: 61kg
Supplied with: Rack, 6 aluminium trays, drain hose, tray holder, 8 GB USB stick, door opening tool and factory test
Maintenance/Service
Consumable items are required to be replaced at the following intervals:
- Bacteriological Filter - Every 400 cycles
- Dust filter - Every 400 cycles
- Door seal - Every 800 cycles or annually whichever comes first
Periodic maintenance is to be carried out by a qualified service technician annually or every 800 cycles. Local guidance should be followed to ensure appropriate servicing.
Warranty: Current warranty conditions will be applied: 2 years or 2000 cycles.
